NAC Memrecam MX-5

The world’s most versatile onboard and offboard camera system designed for critical dynamic applications.

Product serial number

Category

Tel



Product description

Parameters

Video

Down download

The nac MEMRECAM MX is a robust, turnkey solution for multi-camera onboard and offboard automotive testing and occupant safety applications. Each system supports up to eight, tightly synchronized camera views, and integrates seamlessly with all current and legacy MEMRECAM imaging systems.

The M Series utilizes extremely light sensitive image sensors, providing brilliant images complete with up to 8GB per camera view of memory and built-in memory backup protection.

The Integrated Processing Unit provides power, communications, trigger and synchronization for up to eight M-Cam’s, and provides the interconnect technology for integration with all MEMRECAM platforms. All components are compact, light weight, and ruggedized. The versatile MEMRECAM MX high speed camera system is a truly ideal solution for all automotive testing needs.

▏MX-Series Camera Heads

	M-Cam	M-Cam MFT	M2-Cam
Resolution	1920 x 1080 @ 2,000 fps 1920 x 512 @ 5,000 fps	1920 x 1080 @ 2,000 fps 1920 x 512 @ 5,000 fps	1280 x 1024 @ 1,000 fps 640 x 480 @ 4,000 fps
Light Sensitivity	ISO 8,000 (Color) ISO 32,000 (Mono)	ISO 8,000 (Color) ISO 32,000 (Mono)	ISO 2,000 (Color) ISO 10,000 (Mono)
Memory	4GB/8GB (can be segmented up to 16 times)	8GB (can be segmented up to 16 times)	4GB (can be segmented up to 16 times)
Lens Mount	C-Mount	MFT-Mount（4/3）	C-Mount
Dimensions	W75 x H55 x D55mm	MFT-Mount (Micro Four Thirds)	W33 x H33 x D45mm
Weight	450g	550g	100g
Data Security	Autostorage - 32GB SSD; plus Memory Back-up (60 min.)	Autostorage - 32GB SSD; plus Memory Back-up (60 min.)	Autostorage - 32GB SSD; plus Memory Back-up (60 min.)
Impact Resistance	150 G (6 axis) Half Sign 11ms 200 G (6 axis) Half Sign 7ms	Shock 50 G	150 G (6 axis) Half Sign 11ms 200 G (6 axis) Half Sign 7ms
Use	On Board and Off Board	Off Board	On Board and Off Board

MX-5 Integrated Processing Units 4ch 8ch

Camera Ports	Four (4ch)	Four (8ch)
Dimensions	W195 x H60 x D160mm	W195 x H80 x D170mm
Weight	3.5kg	3.6kg
Multi-Camera Control	via PC and Tablet (wired/wireless LAN)	via PC and Tablet (wired/wireless LAN)
Cable	Outer Diameter 7mm; Lengths 5m/10m/20m/40m	Outer Diameter 7mm; Lengths 5m/10m/20m/40m
Impact Resistance	150 G (6 axis) Half Sign 11ms 200 G (6 axis) Half Sign 7ms	150 G (6 axis) Half Sign 11ms 200 G (6 axis) Half Sign 7ms

▎FEATURES

• FullHD@2,000FPS
• PhenomenalLight Sensitivity
• Lens MountOptions:C-Mount andMFT-Mount
•“On Board”, Hi-G Camera Head Options
•“Off Board”, RuggedizedCamera Head with RemoteControl
• Ultra-Small,Lightweight Camera Heads
• ReliableThinCable 7mm (OD) up to40mLong
• Built-inMemoryBackup
• Electronic Shutter
• Hi-G Compact Processing Unit
• MultipleCamera Operation with Precise Synchronization
• Camera Control, Viewing and Setup via PC or Tablet (Wired/WirelessLAN)
• MEMRECAMMXSystem is Backward Compatiblewithall MEMRECAM Platforms
• Camerascanbe Triggered by Shock Using Built-in G-Sensor
